MSI Placa Base MPG B550 GAMING PLUS DDR4 ATX AM4

MSI Placa Base MPG B550 GAMING PLUS DDR4 ATX AM4 MarcamsiModeloMPG B550 GAMING PLUS: (911-7C56-002)Plataforma- ATX (30.5 cm x 24.4 cm)Chipset- AMD® B550 chipsetCPU Soportados- Soporta AMD® RYZEN™ 3ª Generación con Socket AM4Memoria- 4 x DDR4 memory slots, soporta hasta 128GB - - Soporta DDR4 1866/2133/2400/2667/2800/2933/3000/3066/3200 MHz por JEDEC - - Soporta DDR4 2667/2800/2933/3000/3066/3200/3466/3600/3733/3866/4000/4133/4266/4400+ MHz por A-XMP OC MODE) - - Dual channel memory architecture - - Soporta non-ECC UDIMM memory - - Soporta ECC UDIMM memory (non-ECC mode) - - Soporta un-buffered memorySlots Expansión- 1 x PCIe 4.0/ 3.0 x16 slot (PCI_E1) - - 1 x PCIe 3.0 x16 slot (PCI_E3), supports x4 speed - - 2 x PCIe 3.0 x1 slotsGráficos- 1 x DisplayPort, 4096x2160 @ 60Hz - - 1 x HDMI, 4096x2160 @ 24Hz - - Memoria compartida máxima de 16GB - Multi-GPU - - Soporta 2-Way AMD CrossFire™ TechnologyPuertos E/S, Conectores Internos- 1 x 24-pin ATX main power - - 1 x 8-pin ATX 12V power - - 6 x SATA 6Gb/s - - 2 x M.2 slots (M-Key) - - 1 x USB 3.2 Gen 1 5Gbps Type-C - - 1 x USB 3.2 Gen 1 5Gbps - - 2 x USB 2.0 - - 1 x 4-pin CPU fan - - 1 x 4-pin water-pump fan - - 6 x 4-pin system fan - - 1 x Front panel audio - - 2 x System panel - - 1 x Chassis Intrusion - - 1 x 4-pin RGB LED - - 2 x 3-pin RAINBOW LED - - 1 x TPM module - - 1 x Clear CMOS jumper - Externos- PS/2 Combo - - DisplayPort - - 2.5G LAN - - 1G LAN - - HD Audio Connectors - - Flash BIOS Button - - USB 2.0 - - HDMI - - USB 3.2 Gen 1 5Gbps (Type-A) - - USB 3.2 Gen 2 10Gbps (Type-A + Type-C) - - Optical S/PDIF OUTOtras CaracterísticasAlmacenamiento - - 6 x SATA 6Gb/s - - 2 x M.2 slots (Key M) - RAID - - Soporta RAID 0, RAID 1 y RAID 10 para dispositivos SATA - - Soporta RAID 0 y RAID 1 para M.2 NVMe RAID - USB - - 3 x USB 3.2 Gen 1 - - 8 x USB 2.0 - - 2 x USB 3.2 Gen 2 - - 2 x USB 3.2 Gen 1 - Red - - 1 x Realtek® RTL8111H Gigabit LAN - Audio - - Realtek® ALC892 Codec - - 7.1-Channel High Definition Audio - - Soporta S/PDIF - Montaje - - 9 agujeros de montaje - S.O. Compatible - - Soporte para Windows® 10 64-bitFecha Revisión02-09-2020 por MSB
